Lightspeed™ L5
Voice and Data Comms for UAS
- L5 specifically designed for UAS/USV/UGV and robotics platforms
- 10/100 Base-T Ethernet interface
- Physical layer passthrough system (wireless Ethernet cable)
- Does not process or store network data packets
- Data rates up to 20Mbps
- Works with Type 1 inline encryptors
- Ideal for Non-RF launch, monitoring and recovery of unmanned platforms
- Wide Field-of-View, no gimbal or tracking systems needed
- Units can be combined to provide up to 360° AZ communication coverage
- Intra-swarm non-RF communications
- Point-to-point or Broadcast to multiple user modes
- And always available 62Kbps high quality stereophonic voice channel
- Tested and compatible with Anduril Lattice and other unmanned platform protocols
Specifications
Range | Up to 400 m |
Voice, Data | Data up to 20Mbps and concurrent stereophonic Voice channel |
Dimensions | 5.1 x 5.8 x 2.0 in |
Weight | 2.5 lbs |
Power | 12V 700mA (8.5W) |
Angular FOV | Horizontal 30° (+/- 15°); Vertical 20° (+/- 10°) |
Storage Temperature | -40C to 80C |
Operating Temperature | -20C to 55C |
Environmental | Fully sealed / IP rating pending |
Housing | Aluminum |
Mounting | 3/8”-16 tripod / VESA 75 x 75mm |
Connectors | RJ-45 (Ethernet), 2.5mm DC input, 3.5mm Audio |
